Description
Hobbywing EZRun MAX5 HV G2 ESC & 56118SD 800kV Motor Combo – Unmatched 1/5 Scale Brushless Power!
💣 When only the most powerful setup will do — the MAX5 HV G2 delivers extreme torque, smooth throttle response, and smart cooling technology to keep your 1/5 scale rig running cool and wild.
Designed for serious bashing and racing, this sensored ESC/motor combo provides brute power, intelligent control, and waterproof confidence to dominate any terrain.
🔥 Key Features:
EZRun MAX5 G2 ESC
✅ 250A Continuous / 1600A Peak Current – Built for large-scale torque
✅ IP67 Waterproof Rating – Run in mud, snow, or rain
✅ Intelligent Freewheeling Tech – Improves efficiency, lowers temps
✅ Turbo Timing for Increased Acceleration
✅ Adjustable BEC: 6.0V–8.4V @ 25A Peak
✅ 8mm Bullet Connectors for Maximum Current Flow
56118SD G2 Sensored Brushless Motor
✅ 800kV Output – Ideal for 8–12S LiPo setups
✅ 4-Pole Rotor Design – Delivers massive torque and explosive launches
✅ Detachable Design – Easy maintenance access
✅ Waterproof Sensor Interface
✅ Spiral CNC Aluminum Shell for max cooling
✅ Explosion-Proof Rotor Construction
📦 What’s Included:
-
(1) Hobbywing EZRun MAX5 G2 1/5 Scale Waterproof Brushless ESC
-
(1) Hobbywing 56118SD G2 4-Pole Sensored Brushless Motor (800kV)
📊 Specifications:
ESC:
-
Application: 1/5 Scale
-
Continuous Current: 250A
-
Peak Current: 1600A
-
Input Voltage: 6–12S LiPo (up to 44.4V)
-
BEC Output: 6V / 7.4V / 8.4V (Adjustable)
-
Dimensions: 94.5 x 59.4 x 50.9mm
-
Weight: 428.5g
-
Connectors: 8mm bullets
Motor:
-
KV Rating: 800kV
-
Voltage Range: 8–12S LiPo
-
Poles: 4
-
Diameter: 56mm
-
Length: 119.2mm
-
Shaft: 8mm x 30mm
-
Weight: 1277g
-
Front/Rear Bearing: D22D8T7 / D19D5T6
✅ Perfect For:
-
ARRMA Kraton 8S & Outcast 8S
-
Losi 5IVE-T & DBXL-E
-
Custom 1/5 Scale Builds
-
Hardcore Bashers & Competition Racers
🏁 Dominate Your Terrain with Hobbywing’s Most Advanced 1/5 Scale Combo Yet!
💨 From full-throttle launches to long bash sessions, the MAX5 HV G2 + 56118SD 800kV combo gives you unmatched performance, reliability, and confidence in every drive.
